FL650

OVERVIEW

The FL650 is suitable for large scale multi-level, residential or commercial buildings. Producing dedicated C & U profiles between 250mm (10”) and 305mm (12”) up to 2.5mm thickness. This machine's unique punching system provides provisions for easy installation of the HVAC and MEP, along with other electrical and plumbing services, without compromising on joint or profile strength.

Features

The FL650 is suitable for the high volume construction of residential and multi-storey buildings	Automated high line speed up to 1,350m/hr results in a high performing Flooring System manufacturing process.
Joists sit at the same level as the perimeter, achieving a full load transfer for multi-level & modular structures, providing strength and reliability.	The FL650 profile requires fewer screw joins than web joist system.
Smart internet connectivity provides cloud-based data reporting to enable real time production management and technical diagnostics to improve efficiency.	Hot climate hydraulic cooling system to perform in high temperature operating environments and large scale production facilities.

SPECIFICATIONS

Please select the equipment that you would like to see specification information on, select more than one machine to compare details.

FL650
Developed as part of the FRAMECAD optimized Flooring System; the FL650 is suitable for large scale multi-level, residential or commercial buildings. Producing dedicated C & U profiles between 250mm (10”) and 305mm (12”) in steel up to 2.5mm BMT thickness.
F325iT
The F325iT is a highly versatile member of the FRAMECAD manufacturing system. Designed to offer increased production speed, greater flexibility and increased reliability, the F325iT roll-forming machine is best suited for residential and light commercial projects.
F325iT-L
Featuring the same versatility as the F325iT, this machine features an additional 3 tooling stations in the punch block, allowing for more functionality and detailed frame manufacturing.
P325iT
Producing wall frames and trusses for pods, modular and residential structures quickly and economically, the P325iT boasts the industry's fastest automated high line speed of up to 2,880m/hr. Couple with 12 advanced precision punching functions, this machine delivers high productivity and versatile componentry for roof trusses, walls and floor joists.
J325iT
As a dedicated roll forming machine for Web Joists; the J325iT features additional punching tools to manufacture Web Joists up to 40% faster than the rest of the F325iT range. The J325iT allows roll formers to operate a focused Web Joist line whilst other machines focus on framing and trusses.
F450iT
A rapidly high performing solution for producing framing and trusses in heavy residential and light commercial buildings. The F450iT has been designed to handle the heavy gauge steel required to construct 1 to 7 storey structures and outputs 75mm – 150mm profiles.
TF550H
The FRAMECAD TF550H provides heavy duty manufacturing solutions for high volume production. It has been designed to produce heavy duty framing profiles best suited for all frames, roof trusses, floor joists and roof and floor panels where extra strength in construction is required.
TM300iT
The TM300iT has been specially developed as part of the FRAMECAD optimised truss manufacturing system. It produces 75mm standard size C-section trusses designed specifically for maximum strength at minimum cost.
FB150i
Widen your manufacturing and constructing portfolio with the FRAMECAD FB150i Batten (Purlin) machine. A dual profile, dedicated roof batten roll-forming machine, the FB150i is designed for high speed roof batten production.
ST800iT
The ST800iT is a multi-profile system that offers full framing capabilities and is ideal for residential and commercial construction. Compiling of four profiles, three flange heights and six frame and truss tools; the ST800iT produces a range of framing options between 89 (3½")- 203mm (10"), with a gauge range of 0.75-1.60mm (22-16 gauge).
ST900iT
A multi-profile solution for flooring and framing construction, the ideal solution for producing light gauge steel framing and flooring profiles with sizes between 92mm (3⅝" ) and 305mm (12"). Built to handle 0.95 – 2.00mm (20 - 14ga) base metal thickness (BMT), the ST900iT can be used in buildings where structural strength is required.
ST1000-1200H
The FRAMECAD ST series offers a multi profile, heavy duty construction roll-forming system that fulfil the requirements of large scale, multi-purpose projects. It produces an infinite range of section sizes from 50mm (2”) - 300mm (12”) within a steel gauge range of 0.55mm to 2.00mm (24g to 14g) BMT thickness.
PEB300
Producing frames & purlins for portal buildings; the PEB200 has the ability to Ability to roll form C / U / Z and Sigma profiles. The PEB300 provides a truly flexible approach to design and production of PEB and portal framed buildings.
Structure
Save time and investment with engineering design software for cold formed steel structures, with the world's most code compliant system for cold formed steel.
Detailer
FRAMECAD Detailer is a versatile CAD package with world-leading detailing flexibility. Detailer makes it quick and easy to produce designs for automated production.
Factory
FRAMECAD Factory 2 is the factory control software which supports FRAMECAD’s world leading manufacturing solutions. It provides manufacturing and production efficiency while offering ease of operation.
ST950H
The FRAMECAD ST950H is a multi-profile system offering fast, efficient, automated production and flexible profile output. With heavy duty gauge capacity up to 97mils (2.5mm or 12 gauge) this robust system is ideal for the manufacture of load-bearing wall frames, wide spanning roof trusses or long spanning floor joists. Perfect for large scale production of load-bearing, mid-rise cold formed steel projects.
Twin Head Decoiler
The FRAMECAD Twin head decoiler is an option that customers can choose to replace the standard Single head decoiler. This enables customers to always have a spare steel coil loaded on the decoiler which drastically reduces the change over time of coils. This means a big reduction in down time between coil changes for increased production output.
Mobile Factory
The FRAMECAD Mobile Factory is a completely secure, self-contained steel frame roll-forming production facility that can be located anywhere needed, especially in remote areas with little or no infrastructure. Complete with all the equipment necessary for immediate production, the FRAMECAD Mobile Factory is perfect for time critical jobs, or urgent disaster relief housing and reconstruction projects.
TF650H
The TF650H is an ideal solution for heavy duty wall frames, trusses and joists for commercial & residential buildings quickly and economically. Heavy duty system that rolls up to 2.5mm or 97mils material enabling the manufacture and construction of mid rise buildings & industrial.
ST825iT
The ST825iT is the perfect solution for multi profile construction methods for mid-rise residential and light commercial buildings. A flexible building system with up to four profiles which enables a wide range of construction options.
ST925iT
The ST925iT is an ideal solution for multi profile construction projects for midrise commercial, and residential buildings. Able to manufacture from 0.95 - 2.00 or 20 - 14 gauge, it is ideal for manufacturing wall frames, wide spanning roof trusses or long spanning floor joists.

How does the FL650 work?

How much does a FRAMECAD system cost?

Ask Now

Applications

Mid-Rise Residential & Commercial

CFS construction allows developers to meet tight timelines without compromising on quality and allows fast construction of Mid-Rise buildings including; apartments, commercial office buildings, hotels, aged care facilities and more.

Learn More
Industrial Warehousing

Flexible, reliable commercial storage and warehousing needs to be built rapidly and affordably to respond to growth. The FRAMECAD System provides everything required to implement this type of commercial construction – from building design to manufacture and onsite training.

Learn More
Aged Care Facilities

FRAMECAD allows developers to meet tight deadlines without compromising on quality. By supplying rapidly constructed framing components, developers can enjoy the benefits of cost-effective high density construction.

Learn More
Institutional Buildings

The rapid, modern steel frame construction offered by FRAMECAD helps local and central governments construct quality, economical institutional buildings for their communities. Leveraging global reach and experience, FRAMECAD works directly with these agencies and with developers and contractors.

Learn More

The Endless Possibilities of Cold Formed Steel

Whether you build in the residential or non-residential sector, when you need a dependable construction method that delivers projects on time and within budget, you can’t go past cold formed steel (CFS) construction. Download our detailed eBook to learn more about The Way the World Constructs with FRAMECAD
Download our eBook

Watch as this 3-level building uses FRAMECAD to frame the flooring between floors

With a floor area of 3200sqm and a total of over 80 tonnes of steel used, the Zinnia Apartments are comprised of 39 one, two, and three bedroom apartments. The three levels rise to a reasonably complex roof structure, requiring multiple head heights to be maintained across multiple falls throughout the top floor.

Customer Stories

Collaboration successfully pushes limits of CFS innovation for FrameTech

As experts in cold formed steel (CFS) construction, FrameTech knew exactly which method they would use to bring that space to life. Read this case study to learn how did their award-winning CFS facility come to fruition?

Learn More
SBS GROUP DELIVER COST EFFICIENT ENGINEERING & PREFABRICATED FRAMES FOR THE LANGDON APARTMENTS

The Langdon Apartments in New South Wales are a great example of how SBS Group's experience and expertise has delivered an amazing result for a challenging site and design. View the Case Study below and discover how SBS Group can provide the tools to help developers Build Smarter.

Learn More
Cold Formed Steel: Beyond Nonstructural Interior Walls

Some builders assume cold-formed steel is only suitable for nonstructural interior walls, but it can also be used for floor joists, roof trusses, and more. Buildsteel.org take us through the extensive versatility of constructing with CFS.

Learn More
World Steel Association Releases Report on Most Effective Materials for Mid-Rise Construction

This report produced by the World Steel Association aims to provide unbiased information and resources to all stakeholders involved in the construction sector. It details the strong and weak points of various structural solutions

Learn More
